SW520D Tilt Sensor Module
The SW520D Tilt Sensor Module is a compact motion detection module designed to detect changes in orientation, tilt angle, and vibration. It uses the SW520D ball-type tilt switch along with an onboard comparator circuit to provide a stable digital output signal whenever the sensor position changes. This module is widely used in robotics, security systems, automation projects, and DIY electronics applications. Available at Directronics, the SW520D Tilt Sensor Module is ideal for students, hobbyists, makers, educators, and professional engineers working on motion and position sensing projects. (adiy.in)
Features:
• Detects Tilt, Inclination, and Orientation Changes
• Uses High-Sensitivity SW520D Tilt Switch
• Digital Output Signal (HIGH/LOW)
• Onboard LM393 Comparator Circuit
• Adjustable Detection Sensitivity
• Built-In LED Status Indicator
• Compact PCB Module Design
• Low Power Consumption
• Easy Interface with Microcontrollers
• Fixed Mounting Hole for Easy Installation
• Compatible with Arduino, ESP32, STM32, and Raspberry Pi
• Suitable for Robotics and Automation Applications
(adiy.in)
Why Choose SW520D Tilt Sensor Module?
• Provides simple and reliable tilt detection
• No complex programming required for basic operation
• Compact size suitable for embedded projects
• Digital output makes interfacing easy
• Useful for motion-triggered applications
• Ideal for beginners, students, hobbyists, and professionals
Applications:
• Robot Orientation Detection
• Anti-Theft Alarm Systems
• Smart Security Devices
• Tilt Activated Switches
• Vibration and Motion Detection
• Drone and RC Projects
• Robotics Applications
• Toy and Game Controllers
• Industrial Position Monitoring
• Arduino Sensor Projects
Technical Specifications:
• Product Type: Tilt / Motion Sensor Module
• Sensor Model: SW520D Tilt Switch
• Detection Method: Mechanical Ball Tilt Detection
• Operating Voltage: 3.3V–5V DC
• Output Type: Digital Switching Output
• Output Logic: HIGH / LOW
• Controller IC: LM393 Comparator
• Interface Pins: VCC, GND, DO
• Sensitivity Adjustment: Potentiometer
• Output Drive Capability: Up to 15mA (Typical)
• PCB Size: Approx. 32mm × 14mm
• Operating Temperature: 0°C to +80°C (Typical)
• Compatible Controllers: Arduino, ESP32, STM32, Raspberry Pi
Package Includes:
• 1 × SW520D Tilt Sensor Module
Related Products:
• Reed Switch Module
• Vibration Sensor Module
• Accelerometer Sensor Modules
• Arduino Uno
• ESP32 Development Board
• Raspberry Pi Pico W
• Relay Module
• Jumper Wire Bundle (40Pcs)
• Sensor Modules
Why Buy from Directronics?
Directronics provides quality development boards, communication modules, sensors, electronic components, robotics modules, power management solutions, and IoT products for students, makers, educational institutions, startups, and industry professionals. Explore our complete range of Arduino, ESP32, ESP8266, Raspberry Pi, power modules, motor drivers, programming tools, and embedded development products to bring your ideas to life.
Note:
Product images are for illustration purposes only. Actual module design, pin configuration, sensitivity range, and specifications may vary depending on the manufacturing batch. For accurate operation, adjust the onboard potentiometer according to the required tilt sensitivity and mounting orientation.
