The TCRT5000 5-Channel Array Tracking Sensor Module is a reflectance-based infrared sensor array designed for accurate line tracking and surface detection. It consists of five TCRT5000 IR emitter–receiver pairs arranged in a linear array, allowing precise detection of black/white contrast and edge positioning. This module is widely used in line follower robots, AGV systems, and autonomous navigation projects where reliable path detection is required.
Core Sensor Specifications
• Sensor Type: Infrared reflectance tracking sensor array
• Sensor Model: TCRT5000
• Channel Count: 5 independent sensing channels
• Detection Method: IR reflection (black/white contrast)
Electrical & Interface
• Operating Voltage: 3.3 V – 5 V DC
• Output Type: Digital output per channel
• Interface Pins: VCC, GND, D1–D5
• Sensitivity Control: Onboard potentiometer (module dependent)
• Indicator LEDs: Channel status LEDs (variant dependent)
Performance Characteristics
• Fast response suitable for real-time tracking
• High contrast detection on common surfaces
• Consistent performance with proper height adjustment
• Supports straight lines, curves, and intersections
Physical Characteristics
• Module Type: PCB-mounted sensor array
• Sensor Spacing: Evenly aligned for accurate position sensing
• Compact and lightweight design
• Easy mounting on robot chassis
Compatibility
• Arduino Uno / Nano / Mega
• ESP8266 / ESP32
• STM32 and other digital-input MCUs
• Line follower robots and AGVs
• Robotics education kits
Key Advantages
• Multi-sensor array improves tracking accuracy
• Simple digital interfacing
• Works with both 3.3 V and 5 V systems
• Widely used and well documented
Technical Insights
• Optimal sensor height improves reliability
• Ambient light can affect readings without shielding
• Digital outputs simplify firmware logic
• Calibration recommended for different surfaces
Applications
• Line follower robots
• Autonomous guided vehicles (AGV)
• Path and edge detection systems
• Robotics competitions
• Educational and DIY robotics projects
Pro Tip
• Calibrate sensitivity on actual track surface
• Keep sensor surface clean for stable readings
• Maintain consistent distance from ground
• Use array position data for smoother control algorithms
Package Includes
• 1 × TCRT5000 5-Channel Array Tracking Sensor Module
