The TCS3200 Color Recognition Sensor Module is a programmable color detection module designed to identify and measure colors by converting light intensity into a frequency output. It uses an array of photodiodes with red, green, blue, and clear filters, allowing accurate color sensing and comparison. This module is widely used in color sorting machines, robotics, quality inspection, and educational projects involving color detection and analysis.
Core Sensor Specifications
• Sensor Type: Color recognition sensor
• Sensor IC: TCS3200
• Detection Method: RGB photodiode array
• Output Type: Frequency (square wave)
Electrical & Interface
• Operating Voltage: 3.3 V – 5 V
• Output Signal: Digital frequency output
• Control Pins: S0, S1 (frequency scaling), S2, S3 (color filter selection)
• Output Pin: OUT
• Enable Pin: OE (output enable)
Performance Characteristics
• Detects red, green, blue, and clear light components
• Adjustable output frequency scaling
• Fast response suitable for real-time detection
• Repeatable color measurement under controlled lighting
Physical Characteristics
• Module Type: PCB-mounted color sensor
• Sensor Array: 8 × 8 photodiodes
• Onboard Illumination: White LEDs for consistent lighting
• Compact and lightweight construction
Compatibility
• Arduino Uno / Nano / Mega
• ESP8266 / ESP32
• STM32 and other digital-input microcontrollers
• Robotics and automation controllers
Key Advantages
• Simple frequency-based output
• Works with both 3.3 V and 5 V systems
• Integrated illumination improves accuracy
• Widely supported with libraries and examples
Technical Insights
• Requires calibration for accurate color recognition
• Ambient light affects readings without shielding
• Best performance with fixed sensor-to-object distance
• Frequency output measured using timers or interrupts
Applications
• Color sorting and classification systems
• Line-following and object recognition robots
• Quality control and inspection
• Educational color sensing projects
• Embedded vision-like applications
Pro Tip
• Calibrate using known color references
• Shield sensor from external light sources
• Use consistent distance and surface finish
• Average multiple readings for stability
Package Includes
• 1 × TCS3200 Color Recognition Sensor Module
