2N2646 is a TO-92 packaged UJT (Unijunction Transistor) that can be used in timing, pulse generation, and triggering circuits. It is commonly used for relaxation oscillators, SCR/triac triggering, and sawtooth waveform generation. For using it as a trigger device, it can operate with low current and is mainly designed for generating sharp pulses rather than driving heavy loads.
Specification/Features :
-
Type: UJT (Unijunction Transistor)
-
Package: TO-92
-
Typical Applications: Relaxation oscillator, pulse generator, triggering circuits
-
Peak Emitter Current (Ip): around 50mA (varies by manufacturer)
-
Peak Point Emitter Voltage (Vp): depends on intrinsic stand-off ratio (η)
-
Intrinsic Stand-off Ratio (η): typically 0.56 to 0.75
-
Power Dissipation: low power device, depends on operating conditions
-
Best Use: Timing circuits, SCR/triac gate triggering, waveform generation
Package Includes:
-
1 x 2N2646 UJT Transistor (TO-92)
